Product Name: Lug Butterfly Control Valve
Material: Cast Iron, Carbon Steel, ASTM A216 WCB, Stainless Steel, ASTM A351 CF8M, ASTM A351 CF8
Seat Material: EPDM/PTFE
Nominal Size: 2-20 Inch, DN50-DN500
Pressure Rating: Class 150 LB, PN16
Connection Type: Lug
Working Temperature: PDEM: -10°C - 120°C / PTFE: -30°C - 180°C
Applications: Water Treatment, HVAC Systems, Petrochemical Industry, Food and Beverage Industry, Pharmaceutical Industry, etc.
Electric Actuator Features
Actuator: Includes manual function with handwheel for backup.
Switch Types: Offers options for switch type, adjustable, and intelligent actuators. Remote control capability reduces labor costs.
Position Feedback and Monitoring: Provides real-time monitoring of valve position.
Built-in Safety Features: Includes overload protection and position sensors.
Certificate Insurance: Compliant with ISO 5211 and Namur international installation standards, facilitating easy installation and maintenance.
Butterfly Valve Body Features
Compact Design: Simple and compact structure with low operating torque, allowing quick 90° rotation.
Functions: Capable of cutting off and adjusting medium flow.
Coating Options: Butterfly plate can be spray-coated with materials like nylon or polytetrafluoroethylene upon request.
Adjustable Flow: Features linear flow characteristics with excellent adjustment performance.
Stem Seal: Resistant to deformation, preventing common stem leakage.
Reliable Sealing: Replaceable seals ensure dependable two-way sealing.
