Pneumatic Butterfly Control Valve, Cast Iron, 2-20 IN, Wafer

Key Specifications / Features

Our Pneumatic Actuator Butterfly Control Valve Maker offers a comprehensive range of valves designed for diverse industrial applications. These valves are available in sizes from 2 to 20 inches, corresponding to DN50 to DN500, and are constructed from robust Cast Iron and Stainless Steel materials for enhanced durability and corrosion resistance. They are rated for Class 150 to Class 600 LB standards, with a pressure rating range of PN20 to PN100, ensuring they can handle a wide variety of pressure requirements.

Send Inquiry

Category: Butterfly Control Valves

Tags: Pneumatic Butterfly Control Valve , Cast Iron Butterfly Control Valve , Wafer End Butterfly Control Valve .

Detail Information

Product Name: Pneumatic Actuator Butterfly Control Valve
Material: Cast Iron, Carbon Steel ASTM A216 WCB, Stainless Steel ASTM A351 CF8, ASTM A351 CF8M
Seat Material: Rubber, PTFE
Disc Material: Cast Iron,Stainless Steel
Nominal Size: 2-20 Inch, DN50-DN500
Pressure Rating: Class 150-600 LB, PN20-PN100
Connection Type: Wafer
Working Temperature: -30℃ - 180℃
Mode of Action: Double-Acting/Single-Acting(Spring Return)
Operation: Pneumatic Actuator
Applications: HVAC Systems, Industrial Processes, Water Distribution Networks etc

Advantages

Larger Size: Equipped with a longer air cylinder, resulting in higher air consumption.

Stability: Features a reliable pneumatic actuator for consistent long-term performance.

Cost-effective: Offers lower initial costs and requires less maintenance, ensuring a long service life and reduced overall operational expenses.

Corrosion Resistance: Capable of withstanding over 1,000,000 operational cycles, demonstrating excellent resistance to corrosion.

Quick and Responsive: Designed for fast and efficient opening and closing.
